Voltage Range /
Resolution / Accuraccy: 0-1200V / 0.001V / 0.1%/0.05%
Current Range / Resolution / Accuraccy: 0-500A / 0.001A /
0.1%/0.05%
Clamp-on Range / Resolution / Accuraccy: 0.01-100A / 0.01A /
0.15%
Frequency Range / Resolution / Accuraccy: 45-65Hz / 0.001Hz
/ 0.01Hz/0.002Hz
Active power Range / Resolution / Accuraccy: 0 ~ ±Umax x
Imax / 0.01W / 0.5%/0.2%
Reactive power Range / Resolution / Accuraccy: 0 ~ ±Umax x
Imax / 0.01Var / 1%/0.5%
Apparent power Range / Resolution / Accuraccy: 0 ~ ±Umax x
Imax / 0.01VA / 1%/0.5%
Harmonic: 2nd-64th
Power factor Range
/ Resolution / Accuraccy: 0 ~ ±0.9999 / 0.0001 / ±0.001/±0.0005
Phase Range / Resolution / Accuraccy: 0-359.999° / 0.005° /
±0.05°/±0.02°
ELECTRICAL PARAMETERS
Power supply: One-phase power supply (85-265VAC/45-70Hz)
Lithium battery, 5000mAh
Communication port: RS232
Energy constant: 3600imp/kWh, 360000imp/kWhx4
Frequency influence: ≤20ppm/Hz
Pulse interface: TTL energyx6
MECHANICAL PARAMETERS
Main machine (L×W×H) (mm): 240 x 157 x 60
Weight (kg): 1.5
Carrier dimension (L×W×H) (mm): 470 x 380 x 220
Carrier weight (kg): 10.6 (Including three clamp-on (100A),
wires and software)
ENVIRONMENTAL CONDITIONS
Environment: -10 ~ +55°C, 15-85%RHD
Altitude (m): -10 ~ 3500
Temperature: -20°C ~ 65°C
Temperature: ≤25ppm/°C (U/I), ≤50ppm/°C (others)
