ELECTRICAL PARAMETERS
Accuracy class : 0.05%, 0.1%
Power supply: Single phase AC 220V±10% or 110V±10%, 50/60 Hz
or AC 110 V±10%, 50/60 Hz
Communication Port : USB port
AC voltage output
Range(U1,U2,U3): 50 V, 100 V, 200 V, 400 V, 600 V
Adjusting range: (0-120) % RG
Adjust fineness: 0.005% RG
Accuracy: 0.05% RG
Stability: 0.01%/1min
Load capacity: 25 VA
Output distortion degree: ≤0.3% (linear load)
AC current output
Range(I1,I2,I3): 0.5A, 1A, 2.5A, 5A, 10A, 20A
Adjusting range: (0-120) % RG
Adjust fineness: 0.005% RG
Accuracy: 0.05% RG
Stability: 0.01%/1min
Load capacity: 25 VA
Output distortion degree: ≤0.3% (linear load)
DC voltage output
Range: 75 V, 150 V, 300 V, 500 V, 1000 V
Adjusting range: (0-120) % RG
Adjust fineness: 0.005% RG
Accuracy: 0.05% RG
Stability: 0.01%/1min
Load capacity: 25 VA
DC current output
Range: 0.5A, 1A, 2.5A, 5A, 10A, 20A
Adjusting range: (0-120)% RG
Adjust fineness: 0.005% RG
Accuracy: 0.05% RG
Stability: 0.01%/1min
Load capacity: 25 VA
AC power output
Accuracy: 0.05% RG
Stability: 0.01%/1min
Frequency
Frequency range: 45-65 Hz
Resolution: 0.001 Hz
Accuracy: 0.002 Hz
Power factor output
Adjusting range: -1 to 0 to +1
Adjust fineness: 0.0001
Accuracy: 0.0005
Phase angle
Scope: 0°-359.99°
Resolution: 0.01°
Accuracy: 0.05°
Voltage/Current harmonic output
Times: 2nd-31th
Content: 0-40%
Phase: 0°-359.999°
Configuration error: (10% RD + 0.1%), RD refers to the configuration value of harmonic contents
MECHANICAL PARAMETERS
Dimensions (W×D×H) (mm): 460x430x185
Weight (kg): 18
ENVIRONMENTAL CONDITIONS
Working temperature: 0°C to 40°C
Storage conditions: -30°C to 60°C
Relative humidity: ≤85%
