Voltage
- Test voltage output: 0V-480V
- Harmonics generation: free programmable, supporting ODD / EVEN according IEC standards
- Power of the voltage output: Max. 25VA
- Resolution: 1mV
- Setting accuracy: 0.05%
- Stability: 0.003%/h (integration time 150s)
Current
- Test current output: 1mA-100A
- Power of the current output: Max 100VA
- Resolution: 0.002mA
- Setting accuracy: 0.05 at 0.1A – 100A
- Stability: 0.003% / h (integration time 150s)
- Distortion factor: <0.2% for linear resistance load
- Harmonics: 2nd – 21st free programmable, supporting ODD / EVEN harmonic generation
Phase angle
- Setting accuracy: 0.005º
- Range: 0º - 360º
- Resolution: 0.001º
Frequency
- Range: 45Hz – 65Hz
- Resolution: 0.0001 Hz
Pulse output: High frequency output: 1.5625 x 106 Hz
Other
- Dimensions(WxHxD): 432x220x260mm
- Weight(kg): 18
