Input voltage: 24 to 30VDC
Current consumption: 0.4A
Output voltage: 50V to 1200V negative
Output current: 3mA maximum
Control voltage: 10V input gives - 1200V output
Output ripple: Less than 10mV
Line regulation: Better than 50ppm/volt
Load regulation: Better than 50ppm/volt
Connector Information:
Pin 1: Monitor point
Pin 2: Power ground
Pin 3: Internal 10V reference output
Pin 4: Remote shutdown
Pin 5: Power input
Pin 6: Variable reference output
Pin 7: Control 0V reference
Pin 8: HV control input
Pin 9: Power ground
Temperature Co-efficient: better that 50ppm/˚C
Connector: is a PCB-mounted 'D' type, male
