Input specifications
DC input voltage range: 20 to 28VDC
Input current: 2.2A Maximum.
Output specifications
Output voltage range: Near 0kV to 50kV
Available output voltages: 10kV, 20kV, 30kV, 40kV and 50kV (For other output voltages please contact the factory)
Output polarity: Positive or Negative
Voltage load regulation: <0.5%
Voltage line regulation: <0.5%
Voltage ripple: <0.5%
Voltage stability: <0.01%
Control interface: 15 way D connector (female)
Operating temperature: 0 to 40°C
Storage temperature: 0 to 60°C
Relative humidity: Operation 30% to 80%.
Storage: <95% non condensing.
Weight: 2.65kg
Dimensions: Height 65mm, Width 127mm, Length 323mm (including rear connectors)
