Number of operators: one or none
Model: Countertop type (rack option)
Dimensions: L*W*H: 750*660*670(mm)
Weight: 100KG
Operating area: Protective
Reclaiming method: Vacuum suction
Number of electric batches: 1PCS
Number of feeders: 1PCS
Number of work stations: 2PCS
Fixture: custom made
Gas source: 0.4-0.8MPa, oil-free, dry
Power supply: 220V 50HZ
Power: 300W
Applicable screw specifications: Below M3
effectiveness: 1.0s-1.2s/piece
NPL ratio: 1‰ or less (in number of screws)
speed: X, Y, Z-800, 800, 800mm/s
Precision: +/-0.02mm
Applicable product size: L*W*H--120*200*20(mm)
Alarm item: Sliding teeth, leaking, floating height (optional)
Electric batch torque: Adjustable
Operation interface: touch screen
Coordinate storage: 60
Number of locks: 24
Control unit: 4 axis motion controller
Power: Stepper motor / servo motor
Transmission method: Precision timing belt / roller screw
Operating mode: Front/front, front/back
Model switching time: Within 15 minutes
Data communication: USB port export (optional)
Annex: Coordinate adjustment handle
-This machine is a countertop type, compact and compact.
The performance of the machine is similar to that of other series of machines in our company.
Applicable to screws below M3, there is no strict requirement on the tooth type and screw length to diameter ratio.
The working mode is single player mode and unmanned mode, and you can choose freely according to your needs.
-Efficient: 1.0s-1.2s/piece
-can completely replace the manual lock screw station,
-cost - effective,
-versatile,
-can store a variety of products, screw coordinates are
-stable and reliable
-Easy to learn and use
