GAMRY FlexCell Electrochemical Cells (Active Area: 0.775 square inches (nominal); 5.0 cm2 (nominal))

METAL SPECIMEN

Active Area: 0.775 square inches (nominal); 5.0 cm2 (nominal)

Minimum Size: 4.0 cm x 4.0 cm; 4.0 cm diameter (circular)

Maximum Size: 7.5 cm x any length or 11.0 cm x 11.0 cm (rectangular);

11.0 cm diameter (circular)

VESSEL DIMENSIONS

Volume: 1000 ml (minimum), 1300 ml (maximum)

Inner Diameter: 10 cm (nominal)

TEMPERATURE RANGE

Operating: -25ºC to 140ºC

Storage: -40ºC to 180ºC (not assembled)

CHEMICAL COMPATIBILITY

Wetted Materials: Pyrex®, PTFE, Filter Paper

Non-Wetted Materials: Above, plus stainless steel, Viton™, silicone rubber
