Current clamp jaw size: 8mm
Out Singal: AC Current 2500:1
Accuracy: 0.2%
Standard color: Black
Power: N/A
External power supply: N/A
Power consumption: -
Standard Interface: 3.5mm Audio plug
Function: AC leakage current, high current, high harmonic current, complex waveform current, phase, electric energy, power, power factor, etc.
Phase Error: <1°(@50Hz ; 23°C+2°C)
Turn Ratio and Output: can be customized
Out Interface: Can be customized others
Output Line Length: Pliers to adapter 50cm, signal output 2m
Output mode: current-induced output
Sheathing material: ABS
Line Voltage: Line Test under AC 1000V
Working Temperature: -25°C to +60°C
Insulation Resistance: 100MΩ @ 500Vdc
Medium strength: AC3700V/rms (between iron core and shell)
Frequency Characteristics: 10Hz~ 100kHz
