Leak Measurement
Leak ranges
0 to 60.00 cc/h (1.000 cc/min)
0 to 200.0 cc/h (3.333 cc/min)
0 to 600.0 cc/h (10.00 cc/min)
0 to 2000 cc/h (33.33 cc/min)
Accuracy @ 20°C:
10% to 100% range: < 1% reading + 1 digit
0 to 10% range: < 0.1% FSD + 1 digit
Resolution 4 digit display
Temperature Coefficients:
Zero: Automatic
Span: < ± 0.15% per °C
Long Term Drift (span) < ± 1% per year
Pressure Measurement
Pressure Ranges:
5 to 99.99 mbar
20 to 400.0 mbar
50 to 999.9 mbar
0.2 to 2.000 bar
1 to 4.000 bar
3 to 8.000 bar
Accuracy @ 20°C:
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
Resolution 4 digit display
Temperature Coefficients:
Zero: < ± 0.05% per °C
Span: < ± 0.1% per °C
Long Term Drift (span) < ± 1% per year
Electrical
Supply Voltage 24 VDC ± 10% < 500mA
Electrical connections
Power: 2 way detachable screw terminal
Outputs: 20 way detachable screw terminal
Inputs: 16 way detachable screw terminal
RS232: 9 pin D plug
RS485: 5 pin detachable screw terminal
LAN: RJ45 connector, 10base-T/100base-TX Ethernet
USB: Type B connector
Control Inputs Up to 24 Opto-isolated, active high or active low. 5 VDC to 24 VDC into 10 K
Control Outputs Up to 32 Active High transistor output (PNP). 12 VDC to 45 VDC, 120 mA (per channel)
Pneumatic
Media Compatibility Clean dry air or non corrosive gas
Air Supply Pressure Maximum 10 bar gauge, Minimum 5 bar gauge
Regulator Supply Pressure Maximum 16 bar gauge or 35 bar for 30 bar option
Pneumatic Connections
Air supply – 6 mm push-in tube connector
Regulator supply and output – 8 mm push-in tube connector
Test/Reference 1/8” BSPF with adaptation for 6mm O/D push-on tubing.
Up to 5 programmable pneumatic outputs - 4 mm push-in tube connectors
Leak Tightness < 0.2cc/Hour
Construction
Enclosure Steel construction enclosure with paint finish. Suitable for 19” 3U rack mounting.
Dimensions – Rack Case 482 x 133 x 296 mm (W x H x D)
Dimensions – Bench Case 366 x 147 x 296 mm (W x H x D)
Weight 8.5 kg ± 0.5 kg
