Operational Power Supply: AC220V±20V, 50～60Hz
Equipment Power Supply Output Waveform: Sine Wave
Single Tester Output Voltage of Excitation Characteristic: 0～2500V
Excitation Output Current 0～20 A
Single machine output current of turns ratio test: 0～1000A
CT ratio measurement range: 5～25000A/5A（5000A/1A）
PT ratio measurement range: 1～500kV
Load Range: 5～1000VA
Resistance measurement range: 0.1～300Ω
Error: ≤0.5%（0.2%*Reading+0.3%*Range）
Operating Temperature: －10℃～+40℃
Relative Humidity: ＜90RH%
Altitude: ≤1000m
Overall Dimension (Length × Width × Height): 400 *200 * 260（mm）
Weight: ≤22 Kg
