Thermal resolution: 640*480
Detector type: Uncooled focal plane array detector
Thermal sensitivity: ＜30mk
Detector pitch: 17μm
Spectral range: 7.5μm-14μm
FOV: Dependent on the lens configuration
IFOV: Dependent on the lens configuration
Minimum focus distance: Dependent on the lens configuration
Focal distance: Dependent on the lens configuration
Focus type: automatic
Measurement Analysis
Partial emissivity: Support
Measurement parameters: Emissivity; Ambient temperature; Reflected temperature; Relative humidity; Distance; External optics compensation
Temperature range: 20℃-150℃, 0℃-650℃, 300℃-2000℃
Accuracy: ±2℃/±2%
Image display
Palettes: 10 standard palettes and 10 inverted palettes
Mirror mode: Left-right, up-down, center
Video compression: H.264
Radiometric stream: ＜30mk
Measurement tools: 5 points, 10 lines and 10 regions, support Modbus output
Software: AnalyzIR; Open API FOTRIC SDK
Network Connection
Ethernet type: 10M/100M/1000M adaptive
Network protocols: IPv4, UDP, TCP, RTSP, RTCP, RTP
Simultaneous stream: Mainstream and substream: 10; Radiometric stream: 1
IP connection interface: ONVIF
Electrical connection
Power connector: Screw-on wire terminal
Network connector: Screw-on RJ45 with status indicator LED
Alarm input/output: 1 relay output, load capacity: 24V, 1.5A; 1 optocoupler output: Voltage: 3.3-24V，Max current: 35mA; 1 optocoupler input: Voltage: 3.3-24V, Input current: 5mA-15mA
Serial port: RS-485
Power system
Power supply: 12V/24V DC, PoE
Power consumption: 4W
Working temperature: -20℃-65℃
Storage temperature: -40℃-70℃
Relative humidity: <90%
Size(mm): 164.6*80*79 (standard lens）
Weight (g): 993 (standard lens)
Optional lenses
Standard lens: 25°x19°, 0.68mrad, 0.5m, 25.3mm
Wide-angle lens: 50°x38°, 1.36mrad, 0.7m, -12.2mm
Telephoto lens: 12°x9°, 0.33mrad, 5m, -53.9mm
