Features
Image Frame Rate: 30Hz
Measurement Spot: 20
Measurement Line: 10
Measurement Area: 10
Image Mode: Thermal image, Digital camera, Picture in Picture, T-DEF® blend
T-DEF®: Supports thermal and visible light image blend, transparency adjustable from 0% to 100%
T-TWB®: Supports histogram thermal color display
Basic Parameters
Infrared Resolution: 384 × 288
IR Detector Type: Uncooled FPA infrared detector
Thermal Sensitivity (NETD): 40mK (0.04°C) @ 30°C (86°F)
Detector Pitch: 17μm
Spectral Range: 8–14μm
Field of View (FOV): 25° × 19°
Spatial Resolution (IFOV): 1.14 mrad
Minimum Imaging Distance: 0.15m
Focus Mode: Manual focus
Complete Temperature Range: –20°C to 550°C (–4°F to 1022°F)
Accuracy: ±2°C (3.6°F) or ±2%, whichever is greater (ambient temperature at 15–35°C / 59–95°F, target object >0°C, calibration at 1 meter)
PC Software: AnalyzIR®
Display Screen: 3.5-inch Touch Screen
Palettes: 6 Palettes
Digital Camera: 5MP industrial camera
File Format: Radiometric thermal photo (JPEG), digital camera photo
Storage Card: TF card, up to 32GB capacity
Battery Type: Rechargeable Li-ion, 3.6V, 5000mAh
Battery Operating Time: ≥ 4 hours
Language: English
