Channel: 1
Sampling Rate: 2.5MS/s
Bandwidth: 200KHz
Vertical Sensitivity: 10mV/Div - 20V/Div (Progress according to the 1-2-5 way)
Time Base Range: 10μs/Div - 50s/Div (Progress according to the 1-2-5 way)
Voltage Range
X1:±40V (Vpp:80V)
X10:±400V (Vpp:800V)
Trigger Mode: Auto / Normal / Single
Coupling Method: AC/DC
Display: 2.8 Inches / PPI:320*240
USB Charging: 5V/1A
Lithium Battery Capacity: 1000mAh
Square Wave Calibration
Frequency: 1K
Duty cycle: 50%
Size: 99x68.3x19.5mm
Weight: 100g
