FLUKE 718Ex 300G Intrinsically Safe Pressure (-830 mbar to 20 bar, Intrinsically Safe) | EMIN.CO.TH

FLUKE 718Ex 300G Intrinsically Safe Pressure (-830 mbar to 20 bar, Intrinsically Safe)

Name: FLUKE 718Ex 300G Intrinsically Safe Pressure (-830 mbar to 20 bar, Intrinsically Safe)
Brand: FLUKE

ManufacturerFLUKE

Model718Ex 300G

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Range: -830 mbar to 20 bar (internal sensor)
Resolution: 0,0001 bar
Accuracy: 0,05% FS
Functions: Zero, Min, Max, Hold, Damp
Operating Temperature: -10ºC to 55ºC
Display: LCD, 5 digit pressure and current simultaneous
Size: 216 mm L x 94 mm W x 66 mm H (with holster)
Weight: Approx. 992 g (with holster)

Manual

Measurement Accuracy

Pressure

Fluke 718Ex 30G
Range:	-830 mbar to 2 bar (internal sensor)
	Over pressure: 3x FS
Resolution:	0.0001 bar
Accuracy:	0.05% FS
Functions:	Zero, Min, Max, Hold, Damp
	Note: for use with non-corrosive gasses
Fluke 718Ex 100G
Range:	-830 mbar to 7 bar (internal sensor)
	Over pressure: 2x FS
Resolution:	0.001 bar
Accuracy:	0.05% FS
Functions:	Zero, Min, Max, Hold, Damp
	Note: for use with non-corrosive gasses
Fluke 718Ex 300G
Range:	-830 mbar to 20 bar (internal sensor)
	Over pressure: 375 psi, 25 bar
Resolution:	0.0001 bar
Accuracy:	0.05% FS
Functions:	Zero, Min, Max, Hold, Damp
	Note: for use with non-corrosive gasses
Fluke 718Ex series
	via pressure module connector
Range:	29 pressure modules, 2.5 mbar to 700 bar
	Over pressure per pressure module specs
Resolution:	Per pressure module specs
Accuracy:	To 0.025% of full span, per pressure module specs
Functions:	Zero, Min, Max, Hold, Damp
	Note: media compatibility per pressure module specs
Source Pressure, built in pump
Range:	-820 mbar to full scale
Note:	Supported Pressure Units PSI, in. H2O (4 °C), in. H2O (20 °C), kPa, cm H2O (4 °C),
	cm H2O (20 °C), bar, mbar, kg/cm², mmHg, in Hg
