Battery Resistance:
Vdc:
Vac (45 Hz to 500 Hz with 800 Hz filter):
Frequency (displayed with Vac and Aac)2:
AC voltage ripple (20KHz Max):
Adc/Aac (with accessory Fluke i410):
Temperature: 0°C to 60°C/ 2°C
Meter mode: 999 records for each measurement position with time stamp
Sequence mode: Up to 100 profiles and 100 profile templates (Each profile stores up to 450 batteries) with time stamp
Size (HxWxD): 22 cm x 10.3 cm x 5.8 cm
Weight: 850 g
Interface: USB mini
|
Functions |
Range |
Resolution |
Accuracy |
BT508 |
BT510 |
BT520 |
BT5213 |
|
Battery Resistance / Strap Resistance1 |
3 mΩ |
0.001 mΩ |
1% + 8 |
● |
● |
● |
● |
|
30 mΩ |
0.01 mΩ |
0.8% + 6 |
● |
● |
● |
● |
|
|
300 mΩ |
0.1 mΩ |
0.8% + 6 |
● |
● |
● |
● |
|
|
3000 mΩ |
1 mΩ |
0.8% + 6 |
● |
● |
● |
● |
|
|
Vdc |
6 V |
0.001 v |
0.09% + 5 |
● |
● |
● |
● |
|
60 V |
0.01 v |
0.09% + 5 |
● |
● |
● |
● |
|
|
600 V |
0.1 v |
0.09% + 5 |
● |
● |
● |
● |
|
|
1000 v |
1V |
0.09% + 5 |
|
|
|
● |
|
|
Vac (45 Hz to 500 Hz with 800 Hz filter) |
600 v |
0.1 v |
2% + 10 |
|
● |
● |
● |
|
Frequency (displayed with Vac and Aac)2 |
500 Hz |
0.1 Hz |
<span style="font-size:12.0pt;font-family:"Times New Roman","serif"; mso-fareast-font-family:" |
