Voltage: 1000 V/± (0,2 % + 0,01 %)
- Current: Direct input
+ i17xx-flex 1500 12: 150A/± (1 % + 0,02 %), 1500A/± (1 % + 0,02 %)
+ i17xx-flex 3000 24: 300A/± (1 % + 0,02 %),3000A± (1 % + 0,02 %)
+ i17xx-flex 6000 36: 600A/± (1,5 % + 0,03 %), 6000A/± (1,5 % + 0,03 %)
+ Đầu kìm i40s-EL: 4A/± (0,7 % + 0,02 %), 40A/± (0,7 % + 0,02 %)
Frequency: 42,5 Hz to 69 Hz/± (0,1 %)
Auxillary input: ± 10 V dc/ ± (0,2 % + 0,02 %)
Voltage min/max: 1000 V/± (1 % + 0,1 %)
THD on voltage: 1000%/± (2,5 % ± 0,05)
THD on current: 1000%/± (2,5 % ± 0,05)
Cosφ/DPF: 0 <= Cosφ <=1/± 0,025
Power factor: 0 <= PF <=1/± 0,025
IP rating: 50
Demensions: 19.8 cm x 16.7 cm x 5.5 cm
Weight: 1.1 kg
|
Specifications |
||||
|
Accuracy |
||||
|
Parameter |
Range |
Resolution |
Intrinsic Accuracy at Reference Conditions (% of Reading + % of Full Scale) |
|
|
Voltage |
1000 V |
0.1 V |
± (0.2 % + 0.01 %) |
|
|
Current: Direct input |
iFlex1500-12 |
150 A |
0.1 A |
± (1 % + 0.02 %) |
|
1500 A |
1 A |
|||
|
iFlex3000-24 |
300 A |
1 A |
± (1 % + 0.02 %) |
|
|
3000 A |
10 A |
|||
|
iFlex6000-36 |
600 A |
1 A |
± (1.5 % + 0.03 %) |
|
|
6000 A |
10 A |
|||
|
i40s-EL clamp |
4 A |
1 mA |
± (0.7 % + 0.02 %) |
|
|
40 A |
10 mA |
|||
|
Frequency |
42.5 Hz to 69 Hz |
0.01 Hz |
± (0.1 %) |
|
|
Auxillary input |
± 10 V dc |
0.1 mV |
± (0.2 % + 0.02 %) |
|
|
Voltage min/max |
1000 V |
0.1 V |
± (1 % + 0.1 %) |
|
|
Current min/max |
defined by accessory |
defined by accessory |
± (5 % + 0.2 %) |
|
|
Cosφ/DPF |
0 <= Cosφ <=1 |
0.01 |
± 0.025 |
|
|
Power factor |
0 <= PF <=1 |
0.01 |
± 0.025 |
|
|
THD on voltage |
1000 % |
0.1 % |
± (2.5 % ± 0.05) |
|
|
THD on current |
1000 % |
0.1 % |
± (2.5 % ± 0.05) |
|
|
Intrinsic Uncertainty ± (% of reading + % of range)1 |
|||||
|
Parameter |
Influence quantity |
iFlex1500-12 |
iFlex3000-24 |
iFlex6000-36 |
i40S-EL |
|
150A/1500A |
300A/3000A |
<||||
