Range: -12 to 100 PSI, -850 mbar to 7 bar (internal sensor) Over Pressure 3xFS
Resolution: 0.01 psi, 1 mbar
Accuracy: 0.05% of full scale
Functions: Zero, Min, Max, Hold, Damp, Note: for use with non-corrosive gasses
Loop Power Range: 24 V dc
Loop Power Accuracy: +/- 10%
Measure Accuracy Range: 0 to 24 mA
Measure Accuracy Resolution: 0.001 mA
Measure Accuracy: 0.025% + 1 count
Display LCD, 5 digit pressure and current simultaneous
Operating temperature: -10 to 55°C
Maximum voltage: 30V
Size: 216 mm L x 94 mm W x 67 mm (8.5 in. L X 3.72 in. W X 2.61in.)
Weight: Approx. 992g (35 oz)
Shock & Vibration: Random, 2G, 5-500 Hz, 1m drop test
Battery Type: Two 9V batteries, ANSI/NEDA 1604A or IEC 6LR61, Battery life: 4 to 20 hours, typical, depending on functions
