Nominal Size: 5 ft (1.5 m)
External Dimensions (W x D x H): 59.75" x 30" x 46.93" (151.7 x 76.2 x 119.2 cm)
Internal Dimensions (W x D x H): 55.79" x 26.55" x 26.9" (141.7 x 67.4 x 68.3 cm)
Nominal Usable Work Area: 9.5 ft² (0.9 m²)
Face Opening Height: 12.5" (31.7 cm)
Approximate Weight: 274 lb (124 kg)
Materials of Construction
Acrylic: Transparent 0.375" clear acrylic front, side panels, and curved airfoil
Polypropylene: White 0.375" polypropylene baffle, back, and top panels
Phenolic: Black 0.5" phenolic resin base, routed to fit sidewalls for containment
Fan Performance
Voltage: 110–120 VAC
Power: 275 W (each)
Current: 2.25 A (each)
Airflow (with thimble connection): 348 CFM @ 75 LFPM face velocity
Sound Level: 50–55 dB at 3 ft
Filter Specifications
Filter Type: 99.99% efficient 4" pleated HEPA filter
Filter Size: 24" x 14"
Filter Quantity: 2
LED Lighting
Lifetime: Approx. 50,000 hours
Input Power: 575 mA at 12 VDC
Luminous Output: Max 675 lumens
Beam Angle: 120°
Additional Features
Velocity Alarm: Integrated Go/No-Go velocity alarm (0.2 A)
Factory Testing:
ASHRAE 110-2016 containment ≤ 0.050 PPM
Human-as-mannequin test ≤ 0.050 PPM
Accessory Shelf: Optional (for printer or other equipment)
Waste Chute: Optional for safe disposal inside enclosure
