IR Resolution: 640 × 480 pixels
Thermal Sensitivity/NETD: <40 mK at 30°C (24° lens)
Accuracy: ±1°C (±1.8°F): 5 to 100°C (41 to 212°F), ±1%: 100 to 120°C (212 to 248°F), ±2°C (±3.6°F): -40 to 100°C (-40 to 212°F), ±2%: 100 to 650°C (212 to 1202°F), 300 to 2000°C (572 to 3632°F)
Digital Camera: 5 MP, with built-in LED photo/video lamp
Display: 4", 640 ×480 pixel touchscreen LCD with auto-rotation
Storage Media: Removable SD card
IMAGING & OPTICAL
Color Palettes: Iron, Rainbow, Rainbow HC, White hot, Black hot, Arctic, Lava
Detector Type and Pitch: Uncooled microbolometer, 12 µm
Digital Camera: 5 MP, with built-in LED photo/video lamp, disabled when 80° lens in use
Digital Zoom: 1-8x continuous
f-number: 1.3/1.3
Focal length: 29 mm (1.41 in) / 17 mm (.67 in)
Focus: Continuous with laser distance meter (LDM), one-shot LDM, one-shot contrast, manual
Image Frequency: 30 Hz
Lens: DFOV (24°, 14°)
IR Resolution: 640 × 480 pixels
Lens Identification: Automatic
Minimum Focus Distance: .18 m (.59 ft), 24° / 1.0 m (3.28 ft), 14°
Minimum Focus Distance with MSX: .5 m (1.64 ft) / 1.0 m (3.28 ft)
Non-radiometric IR video streaming: H.264 or MPEG-4 over Wi-Fi MJPEG over UVC or Wi-Fi
Picture-in-Picture: Resizable and movable
Radiometric IR video recording: Real-time radiometric recording (.csq)
Radiometric IR video streaming: Yes, over UVC
Spectral Range: 7.5 - 14.0 µm
Thermal Sensitivity/NETD: <40 mK at 30°C (24° lens)
UltraMax: Quadruples pixel count; activated in menu and processed in FLIR reporting software.
Viewfinder: Yes
MEASUREMENT & ANALYSIS
Accuracy: ±1°C (±1.8°F): 5 to 100°C (41 to 212°F), ±1%: 100 to 120°C (212 to 248°F), ±2°C (±3.6°F): -40 to 100°C (-40 to 212°F), ±2%: 100 to 650°C (212 to 1202°F), 300 to 2000°C (572 to 3632°F)
Measurement Presets: No measurement, center spot, hot spot, cold spot, User Preset 1, User Preset 2
Object Temperature Range: -40°C to 120°C (-40°F to 248°F); 0°C to 650°C (32°F to 1202°F) 300°C to 2000°C (572°F to 3632°F)
Spot Meter: 10 ea. in live mode
USER INTERFACE
Display: 4", 640 ×480 pixel touchscreen LCD with auto-rotation
Text: Predefined list or touchscreen keyboard
Voice: 60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth
POWER
Battery operating time: Approx. 4 hours at 25°C (77°F) ambient temperature and typical use
Battery Type: Li-ion battery, charged in camera or on separate charger
ENVIRONMENTAL & CERTIFICATIONS
Operating Temperature Range: -15°C to 50°C (5°F to 122°F)
Safety: EN/UL/CSA/PSE 60950-1
Storage Temperature Range: -40°C to 70°C (-40°F to 158°F)
