Thermal Sensitivity/NETD: <40 mK @ 30°C/86°F (24° lens), <30 mK @ 30°C/86°F (42° lens)
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Digital Camera: 5 MP, with built-in LED photo/video lamp
Display: 4", 640 × 480 pixel touchscreen LCD with auto-rotation
Storage Media: Removable SD card
IMAGING & OPTICAL
Camera software update: Using USB cable or SD card
Color: Black
Color Palettes: Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
Detector Resolution: 640 × 480
Detector Type and Pitch: Uncooled microbolometer, 12 µm
Digital Camera: 5 MP, with built-in LED photo/video lamp
Digital camera FOV: 53° × 41°
Digital Zoom: 1–8× continuous
Field of view (FOV): 24° × 18°, 42° × 32°
f-number: 1.3 (24° lens), 1.1 (42° lens)
Focal Length: 17 mm/0.67 in (24° lens), 10 mm/0.39 in (42° lens)
Focus: Continuous with laser distance meter (LDM), one- shot LDM, one-shot contrast, manual
Frame Rate [Full Window]: 30 Hz
Minimum Focus Distance with MSX: 0.5 m/1.64 ft (24° lens), 0.65 m/2.13 ft (42° lens)
Minimum Focus Distance: 0.15 m/0.49 ft (24° & 42° lens)
Picture-in-Picture: Resizable and movable
Spatial resolution (IFOV): 0.7 mrad/pixel (24° lens), 1.2 mrad/pixel (42° lens)
Spectral Range: 7.5 - 14 µm
MEASUREMENT & ANALYSIS
Accuracy: ±2°C (±3.6°F) or ±2% of reading
Object Temperature Range: -20°C to 120°C (-4°F to 248°F); 0°C to 650°C (32°F to 1202°F); 300°C to 1500°C (572°F to 2732°F)
USER INTERFACE
Display: 4", 640 × 480 pixel touchscreen LCD with auto-rotation
Display Technology: IPS
Touch Screen: Optically bonded PCAP
Voice: 60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth
POWER
Battery operating time: Approx. 4 hours at 25°C (77°F) ambient temperature and typical use
Battery Type: Li-ion battery, charged in camera or on separate charger
Battery voltage: 3.6 V
Battery weight: 195 g (6.89 oz)
Charging system: In camera (AC adapter or 12 V from a vehicle) or two-bay charger
Charging Temperature: 0°C to 45°C (32°F to 113°F)
External Power Operation: AC adapter 90–260 V AC (50/60 Hz) or 12 V from a vehicle (cable with standard plug, optional)
Power Management: Automatic shut-down and sleep mode
Operating Temperature Range: -15°C to 50°C (5°F to 122°F)
Storage Temperature Range: -40°C to 70°C (-40°F to 158°F)
Packaging Size: 500 × 190 × 370 mm (19.7 × 7.5 × 14.6 in)
Size (L x W x H): Lens horizontal: 140 × 201.3 × 167.3 mm (5.5 × 7.9 × 6.6 in)
Weight [battery included]: 1.4 kg (3.1 lb)
