Direct access to our certified experts
- Certifications: MFi (iOS version), RoHS, CE/FCC, CEC-BC, EN61233
- Operating temperature: 0 °C – 35 °C (32 °F to 95 °F) ,
- Battery charging: 0 °C to 30 °C (32 °F to 86 °F)
- Non-operating temperature: -20 °C to 60 °C (-4 °F to 140 °F)
- Size: 68mm W x34mm H x14mm D (2.7in x 1.3in x .6in)
- Weight: 36.5g
- Mechanical shock: Drop from 1.8m (5.9ft)
Video
- Thermal and visual cameras with MSX
- Thermal sensor Pixel size 12μM, 8 – 14μM spectral range
- Thermal resolution 160x120
- Visual resolution 1440x1080
- HFOV / VFOV: 55°± 1°/ 43° ± 1°
- Frame rate: 8.7Hz
- Focus Fixed: 15cm – Infinity
Radiometry
- Scene dynamic range -20 °C to 400 °C (-4 °F to 752 °F)
- Accuracy:
±3°C (5.4 °F) or ±5%, typical Percent of the difference
between ambient and scene temperature. Applicable 60s
after start-up when the unit is within 15 °C to 35 °C (59 °F to 95 °F)
and the scene is within 5 °C to 120 °C (41 °F to 248 °F)
- Thermal sensitivity (MRTD): 150mK
- Emissivity settings Matte: 95%, Semi-Matte: 80%, Semi-Glossy: 60%,
- Glossy: 30% Reflected background temperature is 22 °C (72 °F)
- Shutter: Automatic/Manual
Power
- Battery life: Approximately 1h
- Battery charge: time 40min
Interfaces
- Video: Male USB-C Android)
- Charging: Female USB-C (5V/1A)
App
- Video and still image display/capture: Saved as 1440x1080
- File formats: Photo – radiometric jpeg
Video – MPEG-4 (file format MP4 (Android))
- Capture modes: Video, Photo, Time lapse
- Palettes: Gray (white hot), Hottest, Coldest, Iron, Rainbow, Contrast, Arctic, Lava and Wheel.
- Spot meter: Off / °C / °F. Resolution 0.1 °C / 0.1 °F
- Adjustable MSX distance: 0.3m – Infinity
- Battery charge monitor: 0 – 100%
