Thermal Lens options: 24° furnace, 6° lenses
IR resolution: 640 × 480 pixels
Field of view (FOV): 24°
Focal length: 23 mm
Minimum focus distance: 0.3 m (1.0 ft)
F-number: 2.9
Focus: Autofocus, manual focus
Zoom: 1 – 8× continuous, digital zoom
Detector type: Focal plane array (FPA), cooled InSb
Detector pitch: 15 µm
Sensor cooling: Stirling Microcooler (FLIR MC-3)
Image presentation modes: IR image, visual image
Color palettes
• Arctic
• White hot
• Black hot
• Iron
• Lava
• Rainbow
• Rainbow HC
Radiometric IR video recording: RTRR .csq (compressed) & .seq 15 hz (uncompressed)
Non-radiometric IR or visual video: H.264 compression to memory card, .mpeg4 file format
Radiometric IR video streaming: Over UVC
Non-radiometric IR video streaming
• H.264 (AVC) over RTSP (Wi-Fi)
• MPEG4 over RTSP (Wi-Fi)
• MJPEG over UVC and RTSP (Wi-Fi)
Visual recording: H.264 to memory card
Viewfinder: Built-in, tiltable OLED, 800 × 480 pixels
Built-in digital camera: 5 MP
Measurement and analysis
Thermal sensitivity/NETD: 20 mK @ 30°C (86°F)
Measurement temperature range: -20°C to 1500°C (-4°F to 2732°F)
Accuracy: ±1°C (±1.8°F) for temperature range 0°C, to 100°C (32°F to 212°F) or ±2% of reading for temperature range >100°C (>212°F)
Spotmeter:10
Area: 5 boxes with max./min./average
Profile: 1 line (horizontal or vertical)
Measurement corrections: Reflected temperature, distance, atmospheric transmission, humidity, external optics
Languages: 21
Communication and data storage
FLIR Inspection Route: Enabled in the camera
Cloud services (via Wi-Fi): FLIR Ignite for direct, secure image uploading, organizing, storage, and sharing (required firmware available), wireless file transfer via userweb library
Bluetooth: Communication with headset
Storage media: Removable SD memory card
Image file formats: Standard JPEG, measurement data included. Infrared-only mode.
Communication interfaces: USB 2.0, Bluetooth®, Wi-Fi, HDMI
Video out: HDMI 640 × 480, HDMI 1280 × 720, DVI 640 × 480, DVI 800 × 600
