General
Detector Type: Long-life, uncooled Vox microbolometer
Enclosure: FH R PTZ camera: NEMA 4X PTU unit: aluminum alloy
Input Voltage: 24 V AC (±10%) 24 V DC (±10%)* *Ensure power supply is capped correctly to avoid overheating
Power Consumption: FH-Series R PTZ + PTU Unit: ≤150 W
Size [L × W × H]: tba
Weight: 18.1 kg (41.4 lbs)
Connections & Communications
Control Protocols: Pelco D
Cyber Security
Security: IEEE 802.1X TLS / HTTPS User authentication Access control via firewall User credentials with policy enforcement Digest authentication
Environmental
Humidity: FH R PTZ camera: 0-95% relative humidity PTU unit: <90% relative humidity
IP Rating (dust & water ingress): IP66
Operating Temperature Range: -35°C to 65°C (-31°F to 149°F)
Shock: IEC 60068-2-27 (FH R PTZ camera only)
Storage Temperature: FH R PTZ camera: -55°C to 85°C (-67°F to 185°F) PTU unit: -40°C to 70°C (-40°F to 158°F)
Vandal Resistance: IK10 (except windows; FH R PTZ camera only)
Vibration: IEC 60068-2-64 (FH R PTZ camera only)
Environmental & Certifications
Corrosion: FH R PTZ camera: MIL-STD 810G, 1000 hr salt spray PTU unit: PH 6.5 to 7.2, continuous spraying for 48 hours without surface change
Imaging & Optical
Frame Rate: 30 Hz
Visible Camera Resolution: Full HD 1080p (1920 × 1080)
F_number: f/1.1
Measurement & Analysis
Accuracy: Target below 100°C (212°F): ±5°C (±9°F) Target below 150°C (302°F): ±5% Target above 150°C (302°F): ±15% Measured at 25°C ambient temperature. Inaccuracy can increase at extreme temperatures.
Object Temperature Range:
High Gain Mode: 0°C to 160°C (32°F to 320°F)
Low Gain Mode: 0°C to 380°C (32°F to 716°F)
Other
Optical zoom_Visible: Up to 30x
Surge Protection: FH R PTZ camera: TVS 6000 V lightning protection, surge protection, voltage transient protection PTU Unit power: 2000 V (line to ground 2000 V, line to line 1000 V) Video signal: 1000 V (line to ground 1000 V, line to line 500 V)
PTZ
Pan Angle: 360° continuous
Pan Speed: 0.1°/s to ~55°/s
Presets - Preset Accuracy: Supports 200 valid preset bits; ±0.1° accuracy
Tilt Angle: -75° to ~40°
Tilt Speed: 0.1°/s to ~25°/s
Sensor & Optical
Field of View: 17° × 14°
Storage
Internal Storage: microSD card slot: up to 512 GB on a Class 10 microSD/microSDHC/microSDXC card (minimum 8 GB)
System Integration
Digital I_O: Input: two dry alarm contacts; Output: two relay contacts, 1A max and 24 V AC/30 V DC Normally open or normally closed (configurable)
Ethernet: 100/1000 Mbps
Network APIs: NEXUS SDK, NEXUS CGI, ONVIF PROFILES S, G, and T
Streaming Resolution: Primary and Secondary Streams Thermal: VGA (640 × 512) Visible: 1080p (1920 × 1080), 720p (1280 × 720), VGA (640 × 480)
Supported Protocols: IPv4, HTTP, HTTPS, UPnP, DNS, NTP, RTSP, TCP, UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X
Thermal Camera
Image Uniformity Optimization: Automatic flat-field correction (FFC) - thermal and temporal triggers
Pixel Pitch: 17 µm
Thermal AGC Region of Interest [ROI]: Default, presets, and user-definable to ensure optimal image quality on subjects of interest
Thermal Image Settings: Auto AGC, Digital Detail Enhancement (DDE), brightness, contrast
Video & Recording
Video Compression: H.264/H.265/MJPEG: four independent streams (2 visible, 2 thermal)
Visible Camera
Array format: 640 × 512
Focal Length: 35 mm
Sensitivity: <35 mK @ 25°C (77°F), f/1.0
Spectral Range: 7.5 µm to 13.5 µm
Video Frame Rate: NTSC: 5-30 fps / PAL: 5-25 fps
Visible f number: f/1.6–f/4.4
Visible Camera
Visible Field of View: HFOV: 2.34° to 59.8° / VFOV: 1.48° to 40.5°
Visible Focal Length: 4.5 mm to 135 mm
