Specification:
Common Features:
- IR Resolution: 464 x 348 pixels
- Object Temperature Range: -20°C to 120°C (-4°F to 248°F), 0°C to 650°C (32°F to 1200°F), Optional 300°C to 1500°C (572°F to 1830°F)
- Detector Type and Pitch: Uncooled microbolometer, 17 µm
- Thermal Sensitivity/NETD: < 0.03°C @ 30°C (86°F)
- Spectral Range: 7.5 - 14.0 µm
- Image Frequency: 30 Hz
- Field of View (FOV): 42° x 32° (10 mm lens)
- F-Number: f/1.3, f/1.1
- Lens Identification: Automatic
- Focus: Continuous, one-shot laser distance meter (LDM), one-shot contrast, manual
- Digital Zoom: 1-4x continuous
Image Presentation and Modes:
- Display: 4”, 640 x 480 optically-bonded PCAP touchscreen, with 400 cd/m2 surface brightness
- Digital Camera: 5 MP, 53° x 41° FOV
- Color Palettes: Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
- Image Modes: Infrared, visual, MSX®, Picture-in-Picture
- Picture-in-Picture: Resizable and movable
- MSX®: Embosses visual details on full resolution thermal image
- UltraMax™: Super-resolution process quadruples pixel count, activated in FLIR Tools+
Measurement and Analysis
- Accuracy: ±2°C (±3.6°F) or ±2% of reading for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)
- Alarms: Moisture alarm, insulation alarm, measurement alarms
- Color Alarm (Isotherm): Above/below/interval/condensation/insulation
- Laser Distance Measurement: Yes, on-screen
- Measurement Presets: No measurement, center spot, hot spot, cold spot, User Preset 1, User Preset 2
- Compass, GPS: Yes; automatic GPS image tagging
- METERLiNK®: Yes; several readings
Image Storage
- Storage Media: Removable SD card (8 GB)
- Image File Format: Standard radiometric JPEG, measurement data included
Video Recording and Streaming
- Radiometric IR Video Recording Real-time radiometric recording (.csq)
Non-Radiometric IR or Visual Video: H.264 to memory card
Radiometric IR Video Streaming: Yes, over UVC or Wi-Fi
Non-Radiometric IR Video Streaming: H.264 or MPEG-4 over Wi-Fi, MJPEG over UVC or Wi-Fi
Communication Interfaces: USB 2.0, Bluetooth, Wi-Fi
Video Out: DisplayPort over USB Type-C
Additional Data
Battery Type: Li-ion battery, charged in camera or on separate charger
Battery Operating Time: Approx. 2.5 hours at 25°C (77°F) ambient temperature and typical use
Operating Temperature Range: –15°C to 50°C (5°F to 122°F)
Storage Temperature Range: –40°C to 70°C (-40°F to 158°F)
Shock/Vibration/Encapsulation;Safety: 25 g / IEC 60068-2-27, 2 g / IEC 60068-2-6, IP 54 /IEC 60529; EN/UL/CSA/PSE 60950-1
Weight/Dimensions w/o Lens: 1 kg (2.2 lbs), 27.8 x 11.6 x 11.3 cm (11.0 x 4.6 x 4.4 in)
Box Contents
- Lens 42° x 32° (10 mm): 1
- Batteries: 2
- Battery Charger: 1
- Front Lens/Light Protection: 1
- Hand and Wrist Strap: 1
- Lanyard: 1
- Lens Caps (Front/Rear): 2
- Lens Cleaning Cloth: 1
- 15 W3 A Power Supply: 1
- 8 GB SD Card: 1
- Torx Screwdriver: 1
- USB 2.0 A to USB Type-C Cable: 1
- USB Type-C to HDMI Cable: 1
- USB Type-C to USB Type-C Cable: 1
- User Manual (Printed): 1
