FLIR DM93-2 Industrial Digital Multimeter (10.000 A, 1000.0 V, 40.00 mF)

Display Counts: 40,000

MEASUREMENT & ANALYSIS

AC Current: 10.000 A ± 1.0%

AC Voltage: 1000.0 V ± 0.5%

Capacitance: 40.00 mF ± 0.9%

Category Rating: CAT IV-600 V, CAT III-1000 V

Contact Temperature Type K thermocouple: Yes

Continuity Threshold: 30 Ω ± 0.2%

DC Current: 10.000 A ± 0.2%

DC Voltage: 1000.0 V ± 0.05%

Diode Test: 2 V ± 1.5%

Display Counts: 40,000

Frequency: 100.00 kHz ± 5 digits

Measuring Rate: 10 samples per second

Resistance: 40.00 MΩ ± 0.2%

Temperature Range: -200°C to 1200°C (-328°F to 2192°F) ±1.0%

VFD AC Voltage: 1000.0 V ± 0.5%

COMMUNICATION & DATA STORAGE

Bluetooth range max: 10 m (32 ft)

Data Recording: 10,000 records with METERLiNK

Memory: 99 internal storage locations

POWER

Auto Power Off: Default: 10 minutes

Battery Life: ~100 hours with alkaline batteries (backlight, worklight, and Bluetooth off)

Battery Type: 6 × 1.5 V AAA alkaline batteries

GENERAL

Size (L x W x H): 207.1 mm × 98.1 mm × 60.7 mm (8.15 in × 3.86 in × 2.39 in)

Weight: 601 g (1.33 lb) including batteries

Worklights: Yes

ENVIRONMENTAL & CERTIFICATIONS

Certifications: UL, CE, FCC, UKCA

Drop test: 3 m (9.8 ft)

IP Rating: IP54 dust-protected and splash-resistant

ACCESSORIES

Accessories In the Box: Premium test leads, Type K temperature probe (204°C, 400°F), Warranty card, 6 × AAA Energizer batteries, Quick Start Guide
