Ethernet Interface: Wired
Image Frequency: 30 Hz
Thermal Sensitivity/NETD: <50 mK @ 25°C ambient
Communication & Data Storage
Connection Type: RJ-45
Ethernet: For control, image, and power
Ethernet Communication: GigE Vision / GenICam
Ethernet Interface: Wired
Ethernet Power: Power over Ethernet (PoE)
Ethernet Protocols: GigEVision
Ethernet Standard: IEEE 802.3
Ethernet Type: Gigabit Ethernet
Imaging & Optical
Color: Black
Detector Pitch: 17 µm
F_number: 1.24
Field of view (FOV): 42.1° × 31.9°
Focal Length: 14.2 mm (0.56 in)
Focus: Fixed
Image Frequency: 30 Hz
IR Resolution: 640 × 480 pixels
Minimum Focus Distance: 1.3 m (4.3 ft)
Pixel Format: Mono8 or 16-bit/pixel
Spectral Range: 8–14 µm (LWIR)
Thermal Sensitivity/NETD: <50 mK @ 25°C ambient
General
Package Includes: Infrared camera
Packaging Size: 130 × 140 × 100 mm (5.1 × 5.5 × 3.9 in)
Packaging Type: Cardboard box
Packaging Weight: 0.23 kg (0.51 lb)
Size [L x W x H ] w/o Lens: 59 × 29 × 36 mm (2.32 × 1.14 × 1.42 in)
Weight [without lens]: 67 g (2.4 oz)
Environmental
Humidity (Operating and Storage): Maximum 80% relative humidity, non-condensating
Operating Temperature Range: -35°C to 60°C (-31°F to 140°F)
Storage Temperature Range: -40°C to 80°C (-40°F to 176°F) To avoid possible damage during storage, ensure that the sensor is not exposed to air. Use a lens cap or lens to cover the sensor.
Tripod Mounting: UNC ¼″-20
Power
Power Consumption: 12 V: 2.8 W 24 V: 2.8 W PoE (48 V): 3.5 W
