FLIR A6301 - 17 mm lens Advanced Thermal Camera (640 × 512 pixels; 31.5° × 25.5°; -20°C ~ 200°C)

IR Resolution: 640 × 512

Field of view (FOV): 17 mm lens – 31.5° × 25.5°

Minimum focus distance: 17 mm lens – 60 mm

Thermal Sensitivity/NETD: ≤15 mK at 25°C

Detector Type: High Operating Temperature (HOT) MWIR T2SLS

Spectral Range: 3.4 μm – 5.1 μm

Detector Pitch: 15 μm

F/#: f/2.5

Frame Rate: 30 Hz

Focus: Manual

Temperature Measurement Range: -20°C to 200°C

Accuracy: ≤100°C ±2°C, >100°C ±2% of reading

Sensor Cooling: FLIR FL100 Linear cooler (27,000-hour mean time to failure)

Radiometric IR Video Streaming: GigE Vision

Non-radiometric IR Video Streaming: H.264 or MJPEG over RTSP

Digital Inputs: 2× opto-isolated, Vin(low)= 0–1.5 V, Vin(high)= 3–25 V

Digital Outputs: 3x opto-isolated, 0–48 V DC, max. 350 mA; solid-state opto relay; 1x dedicated as Fault output (NC)

Primary Power Source: PoE+ Type 2 (30 W min) or 18 V–56 V DC

Operating Temperature Range: -20°C to 50°C

Encapsulation: IP50

Weight (w/o lens): 1.32 kg (2.9 lbs)

Size (w/o lens): 200 × 76 × 92 mm (7.9 × 3.0 × 3.6 in)

Weight (w/lens): 1.77 kg (3.9 lbs)

Size (w/lens): 267 × 76 × 92 mm (10.5 in × 3.0 in × 3.6 in)
