Object Temperature Range: -20°C to 450°C (-4°F to 842°F)
IR Resolution: 320 × 240 pixels
Thermal Sensitivity/NETD: <50 mK
Accuracy: At ambient temp. 10°C to 35°C and object temp. above 0°C:
• 0°C to 100°C: ±2°C
• 100°C to 450°C: ±2%
Field of view (FOV): 35° × 27°
Digital Camera: 5 MP, Fixed focus, 71.5° × 56° (84° diagonal) field of view
Image Modes:
• Infrared image
• Visual image
• MSX
• Picture in picture (IR area on visual image)
Display: 3.5 in, auto orientation
Storage Media: Built-in
Object Temperature Range: -20°C to 450°C (-4°F to 842°F)
Automatic Image Adjustment: Automatic level and span
Manual Image Adjustment:
• Manual level and span
• 1-Touch level and span
Camera software update:
• Automatic over Wi-Fi
• USB via computer
Color Palettes: Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
Detector Pitch: 12 µm
Detector Type: Focal plane array, uncooled microbolometer
Digital Zoom: Yes, pinch zoom, 1–4× continuous
Display resolution: 640 × 480 pixels
f-number: 1.4
Focus: Focus free
Minimum Focus Distance: 0.4 m (1.3 ft)
Spatial resolution (IFOV): 2.0 mrad/pixel
Spectral Range: 7.5 to 13 µm
Image Frequency: 9 Hz
Video Streaming: Yes; MSX, Thermal, Visual, Picture in Picture; USB Video Class colorized uncompressed with overlay 9 Hz
