Faith FTL4016P Portable Programmable DC Power Supply (180W, 40.5V, 16.4A, 10mV/10mA)

Power: 180W

Voltage: 40.5V

Current: 16.4A

Resolution: 10mV/10mA

Protection: OVP, OCP, OTP

Interface:

Standard RS232, RS485 interfaces; support SCPI, MODBUS-RTU;

Optional USB/LAN

Other function: Remote sense; external trigger; key LOC; preset 400 groups V/I data

AC input

Voltage: 100~240Vac

Frequency: 47~63Hz

Efficiency: η 80%

Fuse type: 2AT 250V Time-delay fuse

Power factor: PF >0.9

Withsanding: I/P-FG：2KVAC/min ≤5mA

Insulation: O/P-FG：500VDC >100MΩ

Accessory: Power cord *1 PCS, RS232 cable * 1 PCS, test cable * 1 set

Dimension W*H*D: 55*140*315(mm)

Weight: Net: 1.8Kg

Datasheet
