Fall Time: 4 ns
Rise Time: 6 ns
Technology: Si
Unit Weight: 106 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 55 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 125 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 17 ns
Typical Turn-Off Delay Time: 25 ns
Id - Continuous Drain Current: 126 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 98 S
Rds On - Drain-Source Resistance: 3.4 mOhms
Vds - Drain-Source Breakdown Voltage: 80 V
Vgs th - Gate-Source Threshold Voltage: 2 V
