Wavelength range (nm):
P= 0 dBm:
P= 3 dBm: 1490–1610
P= 6 dBm: 1520–1590
Signal to source spontaneous emission ratio: ≥ 90 dB / 0.1 nm (typical)
Side mode suppression ratio (dB): ≥ 45
Stability:
+ Wavelength: ±0.01 nm/h (±0.01 nm / 24 h typical)
+ Output power: ±0.01 dB/h (±0.01 dB / 24 h typical)
Relative intensity noise : < –140 dB/Hz
Spectral width (FWHM) : 150 kHz typical (coherence control off); > 100 MHz (coherence control on)
Wavelength setting accuracy (nm) : ±0.2
Wavelength setting repeatability (nm) : ±0.01 (typical)
Wavelength setting resolution (nm) : 0.01 (0.001 option R)
Tuning speed (step-by-step) (nm/s) : 10 (typical)
Analog modulation : 50 Hz to 50 MHz (external)
Digital modulation : 50 Hz to 1 MHz (internal and external)
Optical isolation (dB) : 35
Output fiber type : SMF or PMF (option M)
Output connector : FC/APC narrow key
Laser safety classification : Class 1M
