SPECIFICATIONS:
IL/ORL optimized DFBs:
Wavelength (nm) 1310 ± 6.5; 1550 ± 6.5
Spectral width (nm): < 1
Output power (dBm) : ≥ 1
Stability (dB) 15 minutes: ±0.07
Attenuation range (dB) : > 9
Modulation : None, 270 Hz, 330 Hz, 1 kHz, 2 kHz, ORL optimized
GENERAL SPECIFICATIONS
Size (H x W x D): 25 mm x 159 mm x 175 mm (1 in x 6 1/4 in x 6 7/8 in)
Weight: 0.35 kg (0.77 lb)
Temperature
Operating: 0 °C to 40 °C (32 °F to 104 °F)
Storage: –40 °C to 70 °C (–40 °F to 158 °F)
Relative humidity : 0 % to 80 % non-condensing
LTB-8 operation Windows 10
Instrument drivers: IVI Drivers, LabVIEW™ drivers and SCPI commands
Remote control (automation): With LTB-8: GPIB (IEEE-488.1, IEEE-488.2), Ethernet and RS-232
