Detected vapors: hydrogen, methane, acetylene, propane, butane
Default calibration: methane CH4
Sensing method: metal-oxide semiconductor
Sampling method: Diffusion
Detection range: 0...100% LEL
Sensor lifetime: > 5 years
Power supply: 24 VDC/AC ±20% (default) or 230 VAC (optional)
Digital interface: UART
Output relays: 2 × SPST relays (switch-over contact), 250 VAC / 30 VDC, 5A max
Alarms: blinking LED, buzzer 85 dB
Default Alarm setpoints: 10% LEL / 25% LEL
Enclosure: grey ABS plastic, wall mount, IP65
Dimensions: H90 × W145 × D55 mm
Operating conditions: -40...+70 °C, <95 %RH (non condensing)
