EVERPRECISION iL700 PCB Conformal Coating Equipment

Moving Area X / Y / Z: 570 / 510 / 100mm (Per Single Valve Calculation)

Vision System: 12-Megapixel Color Camera

Repeatability: +/- 0.01 mm/ axis

I/O Signals: 16 Inputs / 16 Outputs

Conveyor Type: Chain Drive

Adjustable Conveyor Width: 50~600mm

Conveyor Height: 890~940mm

Conveyor Speed: 150mm/sec

Communication Interface: SMEMA

Working Temp.: 10~40 °C

Dimensions WxDxH: 1270*1200*1625mm ((Excluding Additional Parts)

Number of Spray / Dispense Valves: Multi-Axis Rotary Coating System / Dual-Valve System / Triple-Valve System

Moving Speed X&Y / Z: Max. 500 / 250 mm/sec

Data Storage Method: Industrial PC

Drive System/ Stepping Motor: XY Axis Servo Motors / Z Axis Micro Stepping Motor

Conveyor Width Adjustment: Motorized Width Adjustment / Programmable Control

PCB Edge Clearance: ≥6mm

Maximum Load Capacity: 5KG

Conveying Direction: From Left to Right

Power Supply: AC 200~240V

Working Humidity: 20~90% no condensation
