Power Supply: DC6V alkaline dry battery LR03 (1.5V AAAX4)
Display Mode: LCD: 128dotsX64dots; backlight function, suitable for dim places
LCD Size: Display area: 44mmX27mm
Test Method: Clamp CT
Primary High Voltage Current Clamp Test: Range: 0.00A～800A; resolution: 0.01A; accuracy: ±0.5%FS
Primary Flexible Current Clamp Test: Range: 0.0A～3000A; resolution: 0.1A; accuracy: ±1.0%FS
Secondary Current Test: Range: 0.00mA～5A; resolution: 0.01mA; accuracy: ±0.5%FS
Turn Ratio Measurement Range: 1～9999
Turn Ratio Resolution: 0.1
Angle Difference Test: Range: 0～360°; resolution: 1°; accuracy: ±3°
Shift Gears: Fully automatic gear shift
Sampling Rate: 2 times/second
Memory: 3000 groups, press the HOLD button to keep the data and store it automatically (data will not be lost if the battery is powered down or replaced)
Data Hold: Press the HOLD key to hold the data, and then press the HOLD key to cancel the hold
Data Access: Press the HOLD key + POWER key to enter the data access mode
Overflow Display: Over-range overflow function: ”OL" symbol display
No Signal Indication: Prompt “No signal” when the host does not receive the transmitted signal
Automatic Shutdown: After about 15 minutes of power-on, the meter will automatically turn off
Battery Voltage: When the battery voltage is lower than 5.2V±0.3V, the low voltage symbol is displayed to remind the battery to be replaced.
Primary High Voltage Current Clamp Size: Clamp jaw size: Φ48mm; overall size: 255mm×84mm×39mm；
Primary Flexible Current Clamp Size: Clamp jaw size: Φ200mm; overall size: 200mm×245mm×13mm
Secondary Low Voltage Current Clamp Size: Clamp jaw size: Φ16mm; overall size: 110mm×53mm×22mm
Primary High Voltage Current Clamp Transmission Distance: Wireless transmission distance 100m
Host Size: 78mm×165mm×42mm；
Weight: Receiver: about 302g (including battery); total mass: about 6.5kg (including accessories)
External Interference: Avoid extra-strong electromagnetic fields; avoid 433MHz and 315MHz interference at the same frequency
Telescopic Insulating Rod Size: 4300mm
Insulating Rod Withstand Voltage: 110kV
Insulation Strength: Host and detector: AC1000V/rms (between shell and screw)
Working Temperature & Humidity: -25℃～45℃; below 80%RH
Storage Temperature & Humidity: -10℃～60℃; below 70%RH
