Measurement Range & Error
Measurement Parameter/Measurement Range/ Max. Solution/ Basic Error
Current/ AC 0mA~10000A/ 1mA/ ±2%rdg±5dgt
DC Voltage/ DC 0.0V~1000.0V/ 0.1V/ ±1.5%rdg±5dgt
AC Voltage/ AC 0.0V~750.0V/ 0.1V/ ±1.5%rdg±3dgt
Resistance/ 0.000kΩ~2.000kΩ/ 1Ω/ ±2%rdg±5dgt
Basic Specifications
Power Supply: 6V DC(LR03×4 sections Alkaline dry battery)
Display Mode: 2.8 inch TFT true-color LCD Screen; display area: 58mm×44mm
Clamp Jaw Size: φ300mm
Flexible Coil Diameter: Φ7.5mm
Wire Position: The measured wire is in the center position of the clamp.
Memory: 600 groups
Communication Interface: can realize uploading stored data to the computer for easy data analysis.
Communication Line: Length 1.8m
Frequency; 50Hz/60Hz Automatic identification
Shift Gear: Fully automatic shift
Sampling Rate: 2 times/second
Backlight: Yes, Press “*” key to control
Data Hold: Data hold function: “HOLD”symbol display
Overflow Display: Exceed measure range overflow function: “OL”symbol display
Automatic Shutdown: 10 Minutes after power on, the meter shut down automatically without any operation to reduce battery consumption
Battery Voltage: While battery voltage decrease to about 4.8V,low battery voltage symbol display, and remind to replace the battery.
Meter Size: 300mm×470mm×35mm
Weight: Meter: about 272g, total weight: about 755g(include battery & accessory)
Working Current: Backlight on: 80mA; Backlight off: 40mA
Insulation Length: AC 3700V/rms(between the core and outside shell)
Suitable Safety Standard: IEC1010-1, IEC1010-2-032, Pollution level 2, CAT Ⅲ(600V)
Working Temperature & Humidity: -10℃~40℃; below 80%RH
Storage Temperature & Humidity: -10℃~60℃; below 70%RH
