Power Supply: 3V DC LR03×2 PCS alkaline dry battery
LCD Size: 39.2mm×26.3mm
DC Voltage: Range: 400mV/4V/40V/400V/600V | ±(0.5%+5)
AC Voltage: Range: 4V/40V/400V/600V | ±(1.2%+5)
AC Current: Range: 4A/40A/400A/600A | ±(2%+10)
Resistance: Range: 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ | ±(1%+5)
Capacitance: Range: 10nF/100nF/1uF/10uF/100uF/1000uF/10mF | ±(3%+5)
Frequency: Range: 100Hz/1kHz/10kHz/100kHz/1MHz/10MHz/40MHz | ±(0.5%+3)
Temperature: Range: -50°C～1000°C | ±(1%+4)
Automatic Range: √
Manual Range: √
AC Conversion Type: True effective value(TRMS)
Input Protection: √
Automatic Shutdown: About 10 minutes, can be set to no automatic shutdown
Diode Test: Can measure the LED work voltage below 3V
Duty Ratio Measurement: √
NCV (Live line) Measurement: √
Short Circuit Buzzer: √
Low Voltage lndicator: √
Input Impedance: About 10MΩ
Data Hold: √
Blue Backlight: √
Clamp Jaw Size: Can measure max wire diameter Ф27mm
Meter Size: 213×80×35mm
Weight: About 230g (include battery)
Working Temperature: 0℃～40℃ relative humidity <75%
Store Temperature: -10℃～ 50℃ relative humidity <80%
