Power Supply: Alkaline dry battery 6LR61 9V
Display Mode: 4 digits LCD display
LCD Size: 35mm×21.5mm; display area: 32mm×15mm
Current Measurement Range: 0.000mA~60.00A
Solution: 1uA
Measurement Accuracy:±1.5%rdg±5dgt
Clamp Jaw Size: 25mm×30mm
Meter Size: 175mm×70mm×38mm
Weight: 210g(include battery)
Test Mode: Clamp CT, integration method
Sampling Mode: about 2 times/second
Frequency: 50Hz, 60Hz Automatic identification
Shift Gear: Fully automatic shift
Line Voltage: Line measurement below DC 600V
Memory: 99 groups, flicker to display ”FULL” symbol indicate storage full
Peak Hold: Peak capture and hold function, long press HOLD key and not release can display peak value in measurement.
Data Hold: Data hold function: “DH”symbol display
Overflow Display: Exceed measure range overflow function: “OL”symbol display
Communication Interface: USB interface
Auto Shut Down: 5 Minutes after power on, the meter shut down automatically without any operation to reduce battery consumption
Battery Voltage: While battery voltage decrease to about 2.8V,low battery voltage symbol display, and remind to replace the battery.
Working Current: 5mA
Insulating Strength: AC2kV/rms(between the core and outside shell)
Suitable Safety Standard: IEC1010-1, IEC1010-2-032, Pollution level 2, CAT Ⅲ(600V)
Working Temperature & Humidity: 0℃~40℃; below 80%RH
Storage Temperature & Humidity: -10℃~60℃; below 70%RH
