Power Supply: Rechargeable lithium battery 7.4V, 5200mAH, external charger
Display Mode: 5 inch touch colorful screen
Working Current: About 490mA
Clamp Current Sensor (Optional)
Clamp current sensor 015B: 17mmX18mm;
Clamp current sensor 042B: Ф40mm
Clamp current sensor 050B; Ф50mm
Flexible coil current sensor 300FA: Ф300mm
Meter Dimension: 240mmX170mmX68mm
Channel: 3 channels voltage, 4 channels current
Voltage Range: 2V~600V
Current Range
Clamp current sensor 015B: 10mA~10.0A
Clamp current sensor 042B: 0.1A~100A
Clamp current sensor 050B; 1A~1000A
Flexible coil current sensor 300FA: 10A~6000A
Frequency: 40Hz~70Hz
Harmonic: Yes, 2~51 orders
Total Harmonic Distortion: Yes, 2~51 orders, each phase
Three-Phase Unbalance: Yes
Communication Interface: USB
Battery Power Indication: Battery symbol will display battery power, when the battery power too low, the instrument will automatic shutdown
Automatic Shut Down
During record function acting, the meter will not automatic shutdown
During record function off, can setting the automatic shutdown time of 15minutes, 30minutes, 60minutes.
Instrument Weight: Total weight: about 8kg (include all accessories)
Input Impedance: Test voltage input impedance: 1MΩ
Withstand Voltage: The instrument circuit and the housing can withstand 3700V/50Hz sine wave AC voltage for 1 minute.
Insulation: Between the instrument circuit and housing≥10MΩ
Structure: Double insulation, with insulation anti-vibration sheath
Suitable Safety Standard: IEC-61010 CAT III 1000V / CAT IV 600V, IEC-61010-031, IEC-61326, Pollution Degree 2
Working Temperature: -10℃~40℃; Below 80%RH
Storage Temperature: -10℃~60℃; Below 80%RH
Accessories: Host: 1PCS; Instrument bag: 1pcs; Pen probe test lines: 4PCS (each 1PCS of yellow, green, red, black); Alligator clip: 4PCS; Charger 1PCS; 4G Memory card: 1PCS. Clamp current sensor: (optional)
