Clamp Jaw Size: Φ8mm
Power Supply: DC9V alkaline dry battery (1.5V LR6×6)
Working Current:
The maximum power consumption when the backlight is turned on is 135mA, and the battery works continuously for about 6 hours.
Turn off the backlight, the meter consumes 90mA of power, and the battery works continuously for about 9 hours.
Display Mode: 2.8-inch TFT color LCD screen; display area 58mmX44mm
Instrument Size: 196mmX92mmX54mm
Voltage Range: AC 0.00V～600V
Current Range: AC 0.0mA～20.0A
Phase Range: 0.0°～360.0°
Frequency Range: 45.00Hz～65.00Hz
Active Power Range: 0.0W～12kW
Reactive Power Range: 0.0var～12kvar
Apparent Power Range: 0.0VA～12kVA
Power Factor Range: -1.000～1.000
Current Vector Sum: 0mA～60.0A
Phase Sequence
Positive phase: U1, U2, U3 or I1, I2, I3 cursor flashes sequentially from left to right
Reverse phase: U1, U2, U3 or I1, I2, I3 cursor flashes sequentially from right to left
Detection Rate: 2 seconds/time
Data Hold: Press the HOLD key to hold the data during the test, and the ”HD" symbol is displayed
Memory: 500 groups
Communication Interface: USB interface, upload the stored data to the computer, easy to analyze and manage data
Automatic Shutdown: After about 15 minutes of inoperable, the meter automatically shuts down to reduce battery consumption
Backlight Function: Yes, suitable for dim places and night use
Voltage Detection: When the battery voltage is lower than 7.2V, the low battery voltage symbol is displayed to remind the battery to be replaced.
Weight
Host: about 550g (include battery);
total weight: about 2.6kg (include accessories)
Input Impedance: The input impedance of the test voltage is: 1MΩ
Withstand Voltage: The sine wave AC voltage of 1000V/50Hz is tolerated between the instrument line and the housing for 1 minute
Insulation: ≥100MW between the instrument circuit and the sheathed housing
Structure: Double insulation, with insulated anti-vibration sheath
Suitable Safety Standard: IEC61010-1 CAT Ⅲ600V, IEC61010-031, IEC61326, pollution level 2
Working Temperature & Humidity: -10℃～40℃; below 80%RH
Store Temperature & Humidity: -10℃～60℃; below 70%RH
