Espressif Systems ESP32-PICO-V3-02 Bluetooth, Wi-Fi Module in SiP form, ESP32 ECO V3 with 8 MB flash and 2 MB PSRAM inside, dual-core MCU, Wi-Fi & Bluetooth combo, LGA 48-pin, 7*7 mm

Core: LX6

Width: 7 mm

Height: 1.11 mm

Length: 7 mm

Technology: Si

Sensitivity: - 75 dBm

Output Power: 19.5 dBm

Data RAM Size: 2 MB

Data RAM Type: PSRAM

Data Bus Width: 32 bit

Interface Type: I2C, I2S, SPI, UART

Mounting Style: SMD/SMT

Processor Series: ESP-32

Maximum Data Rate: 150 Mbps

Moisture Sensitive: Yes

Operating Frequency: 2.4 GHz

Program Memory Size: 4 MB

Program Memory Type: Flash

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 3 V

Maximum Clock Frequency: 240 MHz

Supply Current Receiving: 116 mA

Supply Current Transmitting: 233 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
