System: Two-zone or three-zone test by means of damper switching
Performance:
Test area:
High temp. exposure range: +60 to +200°C (+140 to +392°F)
Low temp. exposure range: –70 to 0°C (–94 to +32°F)
Temp. fluctuation ±0.5°C (±0.9°F)
Hot chamber:
Temp. heat up time: Ambient temp. to +200°C (+392°F) within 15 min.
Cool chamber:
Temp. pull down time: Ambient temp. to –75°C (–103°F) within 50 min.
Temp. recovery: within 5 min.
Inside Dimensions (W x H x D mm): 650 x 460 x 370
Outside dimensions (W x H x D mm): 1550 x 1900 x 1470 [1505]
Weight: Approx. 1150 kg
Utility requirements:
Allowable ambient conditions: 0 to 40°C (+32 to +104°F)
Power supply: 380/400/415V AC 3ø 50Hz: 50 A
Cooling water supply rate: 3.1 m3/h (reference water temp: +32°C) (water-cooled specification)
Operating cooling water temp. range: +5 to +38°C (water-cooled specification)
INCLUDED ACCESSORIES:
• Specimen basket (18-8 Cr-Ni stainless steel/5 mesh metal basket):
TSA–43
(W230 x H40 x D356 mm/load capacity up to 2.5 kg): 2
TSA–73
(W400 x H40 x D356 mm/load capacity up to 5 kg): 2
TSA–103
(W640 x H40 x D356 mm/load capacity up to 5 kg): 2
TSA–203
(W640 x H40 x D656 mm/load capacity up to 17 kg): 2
TSA–303
(W960 x H40 x D656 mm/load capacity up to 17 kg): 2
• Shelf brackets:
(shelf attachment pitch 60 mm, adjustable in 7 levels): 2 sets
• Cartridge fuse:
5A (200V AC specification): 2
10A (220/380/400/415V AC specification): 1
• Cable port rubber plug: 1
• Nipple (water-cooled specification only): 1
• Strainer (water-cooled specification only): 1
• Strainer element (water-cooled specification only): 1
• Operation manual: 1
Datasheet
