Performance:
Unsaturated control:
Temperature control range: +105.0 to +142.9°C
Humidity control range: 75 to 100%rh
Pressure range: 0.020 to 0.196 MPa (Gauge)
Wet-saturated control:
Dải nhiệt độ: +105.0 to +132.9°C
Dải áp suất: 0.020 to 0.196 MPa (Gauge)
Dry & wet-bulb temperature control (M/MD type):
Temp. heat-up:
Temperature control range: +105.6 to +142.9°C
Humidity control range: 75 to 95%rh
Test process:
Temperature control range: +105.6 to +142.9°C
Humidity control range: 75 to 98%rh
Pressure range: 0.020 to 0.196 MPa (Gauge)
Temp. pull-down:
Temperature control range: +50.0 to +95.0°C
Temperature pull down time: +142.9°C / 75%rh to +85.0°C / 85%rh (Approx. 120 min.)
Hold process:
Temperature control range: +50.0 to +95.0°C
Humidity control range: 75 to 95%rh
Dimensions:
Interior volume: 21 L x 2
Test area dimensions: ø294 x D318(296) mm
Chamber outer dimensions (W × H × D mm): 760 × 1796 × 1000
Weight: 350 kg
Utility requirements:
Allowable ambient conditions: +5 to +40°C (+41 to +104°F)
Power supply: 220V AC 1ø 50/60Hz: 22.8A
230V AC 1ø 50Hz: 21.8 A
INCLUDED ACCESSORIES:
• Shelf (large/small): 2 each
EHS-212MD/412MD Large: 286 (W) × 288 (D) mm
Small: 234 (W) × 288 (D) mm
EHS-222MD Large: 386 (W) × 396 (D) mm
Small: 280 (W) × 416 (D) mm
• Specimen signal terminal Pin type, (125 VAC/VDC, 1 A): 12 (MD type: 24)
• Wet bulb wick (for M/MD type only): 50 (MD type: 100)
• Cartridge fuse 250: 7 (MD type: 14)
• Hose nipple: 1
• Eyebolt: 4 (for MD type only)
• Operation manual: 1
• Breaker handle cover: 1 (MD type: 24)
