Stainless Steel Side Walls: 110-130 VAC, 50/60 Hz
Nominal Size: 0.9 meter (3')
External Dimensions (W x D x H):
Without Arm Rest: 1035 x 815 x 1570 mm
With Arm Rest: 1035 x 873 x 1570 mm
Internal Dimensions (W x D x H): 915 x 625 x 720 mm
Usable Work Area: 0.47 m^2 (5.0 sq. ft.)
Sash opening: Available in 203 mm (8”)
Maximum Sash Opening: 575 mm (22.6”)
Average Airflow Velocity:
Inflow:
203 mm (8”): 0.53 m/s (105 fpm)
Downflow:
203 mm (8”): 0.30 m/s (60 fpm)
Airflow Volume:
Inflow:
203 mm (8”): 356 m^3/h (210 cfm)
Downflow:
203 mm (8”): 581 m^3/h (345 cfm)
Exhaust:
203 mm (8”): 356 m^3/h (210 cfm)
Additional Static Pressure for Optional Thimble Exhaust Collar (Measured 360mm or 14“ from the top of exhaust collar):
203 mm (8”): 15-25 Pa
Required Exhaust with Optional Thimble Exhaust Collar:
203 mm (8”): 390 m^3/h (230 cfm)
ULPA Filter Typical Efficiency: ≥99.999% for particle size between 0.1 to 0.3 microns
Sound Emission (dBA) NSF / ANSI 49:
203 mm (8”): 57
Light Intensity: ≥ 1200 lux (111 ft-cd)
Electrical Rating (8):
220-230 VAC 50/60V
Full Load Amps exclude 5A EO:
203 mm (8”): 6 A
Electrical Rating (9):
110-120 VAC 50/60V
Full Load Amps exclude 5A EO:
203 mm (8”): 10 A
Cabinet Construction:
Main body: Electro-galvanized steel with white oven-baked epoxy-polyester Isocide™ antimicrobial powder-coated finish, 1.5 mm (0.06”) / 16 gauge thick
Work Zone: Stainless steel type 304 with no.4 finish, 1.5 mm (0.06”) / 16 gauge thick
Net Weight: 243 Kg (536 lbs)
