220-240 VAC, 50/60 Hz, 1Ø
Nominal size: 2.4 meter
External Dimensions: (W x D x H) 2400 x 770 x 1500 mm
Internal Work Area, Dimensions: (W x D x H) 2200 x 592 x 1259 mm
Exhaust Volume/ Static Pressure Required Face Velocity of 0.5 m/s (100 fpm) at Full Open Sash: 2483 cmh at 95 Pa 1462 cfm at 0.38" WG
Exhaust Outlet Diameter and Material: 305 mm, EG Powdercoat
Number of Exhaust Collars: 2
Fluorescent Light Intensity: 800 lux
Construction:
Main Body: EG steel with oven-baked Epoxy-polyester hybrid Isocide™ powder coating
Internal Liner & Baffle System: Esco Resinate™ phenolic resin laminates
Worktop: Phenolic Resin
Sash Specification:
Sash Material: Frameless tempered safety glass
Sash Configuration: Vertical
Sloping: 8° slope
Maximum Sash Opening: 550 mm (21.7")
Power Consumption: 25 W (Fluorescent Lighting Only) / 60 W (Fluorescent Lighting and Microprocessor Control System)
Electrical*:
Cabinet Full Load Amps (FLA): 6 A
Cabinet BTU/Hr**: 341
Net Weight***: 283 Kg
*The maximum rating of all the electrical outlets combined is 5 Amp. Please contact Esco if you need electrical outlets with higher capacity.
**Cabinet BTU = Cabinet nominal power x 3.41214
***Fume hood unit only. Excludes base cabinet/ optional stand.
