Stainless steel Side: 230 VAC, 50/60 Hz
Nominal Size: 5 ft
External Dimensions (W x D x H):
Width: 1645 mm
Depth without Arm Rest: 753 mm (29.5")
Depth with Arm Rest: 810 mm (32.0")
Height: 1400 mm (54.8")
Gross Internal Dimensions (W x D x H):
Width: 1525 mm
Depth: 580 mm (22.8")
Height: 660 mm (26.0")
Usable Work Area: 0.71 m2
Tested Opening: 175 mm (7")
Work Opening: 190 mm (7.5")
Maximum Opening: 475 mm (18.7")
Average Airflow Velocity:
Inflow: 0.45 m/s (90 fpm)
Downflow: 0.30 m/s (60 fpm)
Airflow Volume:
Inflow: 432 cmh
Downflow: 922 cmh
Exhaust: 432 cmh
Required Exhaust with Optional Thimble Exhaust Collar: 615 m3 /h
Static Pressure for Optional Thimble Exhaust Collar: 35 Pa / 0.14 in H2O
ULPA Filter Typical Efficiency:
>99.999% at 0.1 to 0.3 micron, ULPA as per IEST-RP-CC001.3 USA
>99.999% at MPPS, H14 as per EN 1822 EU
Sound Emission:
NSF / ANSI 49: 58.2 dBA
EN 12469: 53.6 dBA
Fluorescent Lamp Intensity (Lux): 1227
Cabinet Construction:
Main body: 1.2 mm (0.05") 18 gauge electro-galvanized steel with white oven-baked epoxy-polyester IsocideTM antimicrobial powder-coated finish
Work Zone: 1.5 mm (0.06") 16 gauge stainless steel, type 304, with 4B finish
Side Walls: 1.5 mm (0.06") 16 gauge stainless steel, type 304, with 4B finish
Electrical:
Cabinet Full Load Amps (FLA): 4.3 A
Nominal Power Consumption (W): 211
Net Weight: 288 Kg (Cabinet only, excludes optional stand)
