External Dimensions (W x D x H): 1340 mm x 731 mm x 1395 mm
Gross Internal Dimensions (W x D x H): 1220 x 660 x 670 mm
Usable Work Area: 0.76 m^2
Maximum Window Opening (at 90° opening): 565 mm
Working Opening: 203 mm
Average Inflow Velocity: 0.85 m/s
Airflow Volume:
Inflow: 758 m^3/h
Exhaust: 758 m^3/h
Required Exhaust with Optional Thimble Exhaust Collar: 1219 m3 /h (717 cfm)
Static Pressure for Optional Thimble Exhaust Collar: 85 Pa (0.34 in H2O)
HEPA Filter Typical Efficiency:
>99.999% at 0.1 to 0.3 micron, ULPA as per IEST-RP-CC001.3 USA
>99.999% at MPPS, H14 as per EN 1822 EU
Sound Emission in Typical Lab Room per EN 12469: 48.4 dBA
Fluorescent Lamp Intensity (lux): >1200 lux (>111 foot candles)
Cabinet Construction:
Main body: 1.2 mm (0.08") /18 gauge EG Steel with IsocideTM Oven-Baked Epoxy-Polyester Powder Coating
Work Zone Tray: 1.2 mm (0.08")/18 gauge, SS 304, 4B Finish
Side Walls: 5 mm (0.2") UV Absorbing Tempered Glass
Electrical:
FLA (Full Load Amps): 8.1
Heat Load (BTU / Hr): 628
Nominal Power Consumption: 184 W
Net Weight: 230 kg
