Pitch: 1.27 mm (0.05 in)
Data Rate: 3 Gbps
Unit Weight: 1.580 g
Stack Height: 1.75 mm
Current Rating: 1 A
Mounting Angle: Vertical
Mounting Style: Mounting Peg
Number of Rows: 2 Row
Contact Plating: Gold
Contact Material: Copper Alloy
Housing Material: Liquid Crystal Polymer (LCP)
Maximum Data Rate: 3 Gbps
Termination Style: Solder
Flammability Rating: UL 94 V-0
Number of Positions: 68 Position
Insulation Resistance: 10 GOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
