Max. RCF: 20913 × g
Max. RCF with fixed-angle rotor: 20913 × g
Max. RCF with swing-bucket rotor: 4500 × g
Max. RCF with plate rotor: 2250 × g
Speed: 200 – 14,000 rpm (10 rpm steps)
Rotors available: 12
Max. capacity: 4 × 250 mL/ 2 × 5 MTP
Acceleration/braking ramps: 10/10
Number of programs: 35 user-defined programs
Timer: 1 min to 99 min, with continuous run function, short-spin
Noise level: < 58 dB(A)
Power supply: 230 V, 50 – 60 Hz
Max. power consumption: 1650 W
Dimensions (W × D × H): 63.4 × 55.0 × 34.2 cm / 25.0 × 21.7 × 13.5 in
Footprint (dimensions w/o front panel, WxD): 64 × 50 cm / 25 × 21.7 in
Product weight: 80 kg / 176.4 lb
Height (with open lid): 74 cm / 29 in
Coolingnon-refrigerated : refrigerated
Temperature range: -9 °C to +40 °C
Max. capacity
Conical tubes: 40 × 15 mL (with Rotor F-35-48-17) / 16 × 50 mL
Plates: 10 × MTP/ 2 × DWP
Blood collection tubes: 56 × 13 mm/ 52 × 16 mm
Noise level
Rotor FA-45-6-30 (6×50 mL): <54 dB(A)
Rotor S-4-104 (4×750 mL): –
Rotor S-4-72 (4×250 mL): <58 dB(A)
Configuration includes:
Main unit
Swing-bucket rotor S-4-72 (maximum speed: 3234 × g (4,200 rpm))
Supplied with adapters for centrifugation of up to 16 × 50 mL Falcon tubes per unit; and 32 × 15 mL Falcon tubes per unit.
*Images for illustrative purposes only.
