Environmental M5-A-S2 Professional (Isokinetic)

Qty. Part # Description

(1) A-2000 Automatic Data Logging Console
(1) A-2000-PC PC Compatible Laptop With Custom Software
(1) P0523-101Q Enclosed Housing Pump with Stainless Quick Connects
(1) M5-PTC Pump Transport Case
(1) M5-CTC Console Transport Case
(1) M5-SC6 Modular Sample Case, Hot Box and 6 Impinger Cold Box
(1) PRA-S5 Heated Stainless Steel LIned Probe Assembly, 5' Effective
(2) PRL-P5 Pyrex Probe Liner, 5' Effective, #28 Ball With O-Ring
(1) US-25-A Umbilical Cable 25' with Additional Pressure Lines
(1) M5-UA-A Umbilical Adapter With Venturi
(1) PRNS-S Stainless Steel Nozzle Set, 7 sizes 1/8" - 1/2"
(1) GPBO-3C Professional Glassware Set with Transport Case
(1) GF3-107 Glass Fiber Filters, Box of 100
(1) M5-CK7 Probe Brush
(4) M5-CK5 Probe Brush Extension Rod, (18")
(2) M5-SRS-5 Suspension Rail System

M5-A-S2 (Professional)

The M5-A-S2 Professional Auto Isokinetic system is designed with continuous auto data logging capabilities and uses a Venturi to monitor and signal pressure adjustments automatically. The heart of the system is the A-2000 console and utilizes field tested probe assemblies, liners, and sample cases already in use by testers. The M5-A-S2 system employs a Carbon Vane Oiless Pump and comes with additional calibration equipment, and cases for added protection during transport. The Auto Isokinetic M5-S1 system reduces manpower and operator error while expediting reporting.

Features

- Automatic Sampling Console with Carbon Vane Oiless Pump

- Transport Cases for Console, Pump, & Glassware

- Brass Critical Orifice Set for Console Calibration

- Sample Cases, including Hot Box and Impinger Box

- Stainless Steel Lined Probe Assembly

- Stainless Steel Nozzles

- Umbilical with an Adapter Designed with Additional Pressure Lines

- Double Set of Method 5 Glassware in a Transport Case

- Clean Out Brush

- Nomograph or Calculator with Custom Software

- Suspension Rail System
